Intel Desktop Board D2500CC Technical Product Specification
78
Table 45. Port 80h POST Codes
Port 80 Code Progress Code Enumeration
ACPI S States
0x00,0x01,0x02,0x03,0x04,0x05 Entering S0, S2, S3, S4, or S5 state
0x10,0x20,0x30 Resuming from S2, S3, S4, or S5 state
PEI before MRC
PEI Platform driver
0x11 Set boot mode, GPIO init
0x12 Early chipset register programming
0x13 Basic chipset initialization
0x14 LAN init
0x15 Exit early platform init driver
PEI SMBUS
0x16 SMBUS driver init
0x17 Entry to SMBUS execute read/write
0x18 Exit SMBUS execute read/write
Memory
0x21 MRC entry point
0x24 Detecting presence of memory DIMMs
0x25 Override Detected DIMM settings
0x27 Configuring memory.
0x28 Testing memory
PEIMs/Recovery
0x31 Crisis Recovery has initiated
0x33 Loading recovery capsule
0x34 Start recovery capsule / valid capsule is found
CPU Initialization
CPU PEI Phase
0x41 Begin CPU PEI Init
0x42 XMM instruction enabling
0x43 End CPU PEI Init
CPU PEI SMM Phase
0x44 Begin CPU SMM Init smm relocate bases
0x45 Smm relocate bases for APs
0x46 End CPU SMM Init
continued
