Intel D2500CC User Manual

Technical Reference
51
2.2.2.3 Power Supply Connector
The board has a 2 x 12 power connector (see Table 27). This board requires a TFX12V
or SFX12V power supply.
Table 27. Power Connector
Pin Signal Name Pin Signal Name
1 +3.3 V 13 +3.3 V
2 +3.3 V 14 -12 V
3 Ground 15 Ground
4 +5 V 16 PS-ON# (power supply remote on/off)
5 Ground 17 Ground
6 +5 V 18 Ground
7 Ground 19 Ground
8 PWRGD (Power Good) 20 No connect
9 +5 V (Standby) 21 +5 V
10 +12 V 22 +5 V
11 +12 V 23 +5 V
12 No connect 24 Ground
