Intel D525 User Manual

6
Connectors
Connector Name
DC12V1 DC 12V Power–in Connector
ATX12V ATX 12V Power Connector
KBMS PS/2 KB/MS Connector
COM1 Serial Port Connector
VGA Video Graphic Attach Connector
PARALLEL Parallel Port Connector
USB USB 2.0 Port Connector x2
UL1(Middle & Bottom) USB 2.0 Port Connector x2
UL1(Top) RJ-45 LAN Connector
AUDIO (Top) Audio Line Out Connector
AUDIO (Bottom) Audio MIC Connector
SATA2 SATAII Connector
PWOUT SATA Power out Connector
MINI_HALF Half-size Mini-PCIE Connector
MSATA Full-size Mini-SATA Connector
Headers
Header Name Description
FP_AUDIO Front Panel Audio Header 9-pin Block
HDMI_SPDIF HDMI_SPDIF Out Header 2-pin Block
COM 2/3/4 Serial Port Headers 9-pin Block
USB2 USB 2.0 Port Header 9-pin Block
GPIO_CON
GPIO
Header
10-pin block
PWRLED Power LED Header 3-pin Block
SPEAK Speaker Header 4-pin Block
JW_FP Front Panel Header(PWR LED/ HD
LED/Power Button /Reset)
9-pin Block
LVDS LVDS Header 30-pin Block
INVERTER LVDS Inverter 6-pin Block
CPUFAN/ SYSFAN1 FAN Headers
3-pin Block

Intel D525 Specifications

General

CPU	Intel Atom D525
Memory Type	DDR3
Max Memory	4GB
Storage Interfaces	2 x SATA 3Gb/s
USB Ports	6 x USB 2.0
Form Factor	Mini-ITX
Memory Slots	2
Graphics	Intel GMA 3150
Expansion Slots	1 x PCI
Audio	Realtek ALC662
