Motherboard Jumper Position
Jumper
Jumper Name Description
JP1 INVERTER VCC 3.3V/5V/12V Select 4-pin Block
JP2 LVDS VCC 3.3V/5V/12V Select 4-pin Block
JBAT CMOS RAM Clear Function Setting 3-pin Block
JP5 K/B Power on Function Select
3-pin Block
JP7 COM1 Port Pin9 Function Select 6-Pin Block
JP3 COM2 Header Pin9 Function Select 6-Pin Block
JBAT
JP5
JP7
JP1
JP2
JP3
