Intel D525 User Manual

37
The optional settings are: [Disabled]; [Enabled].
► Smart Fan Configuration
CPUFAN / SYSFAN1 Smart Mode
When set as [Enabled], the following sub-items shall appear:
CPUFAN / SYSFAN1 Full Speed Temp
Use this item to set a degree for CPUFAN/SYSFAN1. FAN will run at full speed
when above the set temperature value.
CPUFAN / SYSFAN1 Idle Temp
Use this item to set a degree for CPUFAN/SYSFAN1. FAN will idle speed when
below the set temperature value.
CPUFAN / SYSFAN1 Idle Speed Duty
Use this item to set idle speed duty for CPUFAN/SYSFAN1.
CPU Temperature/ System Temperature /CPUFAN Speed / SYSFAN1 Speed /
Vcore/ /NB1.05V/5VSB/VDIMM/ +5V/+12V/Vcc3V
This will show the CPU/FAN/System voltage chart and FAN Speed, etc.

Intel D525 Specifications

General

CPU	Intel Atom D525
Memory Type	DDR3
Max Memory	4GB
Storage Interfaces	2 x SATA 3Gb/s
USB Ports	6 x USB 2.0
Form Factor	Mini-ITX
Memory Slots	2
Graphics	Intel GMA 3150
Expansion Slots	1 x PCI
Audio	Realtek ALC662
