Intel D945GTP User Manual

Desktop Board Features
13
Table 3. Desktop Boards D945GNT Components
Label Description
A Rear fan header (4-pin, fan speed control)
B PCI Express x1 connectors
C Front panel audio header
D PCI Express x16 connector
E 12 V processor core voltage connector (2x2)
F Rear chassis fan header 1 (3-pin, fan speed control)
G Processor socket
H Processor fan header (4-pin, fan speed control)
I Main power connector (2x12)
J Diskette drive connector
K IDE connector
L Front chassis fan header (3-pin, fan speed control)
M BIOS configuration jumper
N Chassis intrusion header
O Serial ATA connectors
P Front panel header
Q Alternate power LED header
R Hi-speed USB 2.0 headers
S IEEE 1394a headers (optional)
T PCI bus add-in card connectors

Intel D945GTP Specifications

General

Form Factor	ATX
Processor Support	Intel Pentium 4, Pentium D, Celeron D
Socket Type	LGA 775
Memory Type	DDR2
Memory Slots	4
Maximum Memory	4 GB
Graphics	Intel GMA 950
Audio	Intel High Definition Audio
Ethernet	10/100/1000 Mbps
Expansion Slots	1 x PCI Express x16, 3 x PCI Express x1, 3 x PCI
USB Ports	8 x USB 2.0
Chipset	Intel 945G Express
Storage Interfaces	4 x SATA 3.0 Gb/s, 1 x PATA
