2 Installing and Replacing Desktop
Board Components
This chapter tells you how to:
• Install the I/O shield
• Install and remove the desktop board
• Install and remove a processor and memory
• Install and remove a PCI Express x16 card
• Connect the IDE and Serial ATA cables
• Connect internal headers
• Set up flexible 6-channel audio with jack re-tasking
• Connect fans and power cables
• Locate other connectors
• Set the BIOS configuration jumper
• Clear passwords
• Replace the battery
Before You Begin
CAUTIONS
The procedures in this chapter assume familiarity with the general terminology associated with
personal computers and with the safety practices and regulatory compliance required for using and
modifying electronic equipment.
Disconnect the computer from its power source and from any telecommunications links, networks,
or modems before performing any of the procedures described in this chapter. Failure to
disconnect power, telecommunications links, networks, or modems before you open the computer or
perform any procedures can result in personal injury or equipment damage. Some circuitry on the
board can continue to operate even though the front panel power button is off.
NOTE
Refer to Appendix B for regulatory requirements.
