Intel D945GTP User Manual

Installing and Replacing Desktop Board Components
37
Three DIMMs
Install a matched pair of DIMMs equal in speed and size in DIMM 0 (blue) and DIMM 1 (black) of
channel A. Install a DIMM equal in speed and total size of the DIMMs installed in channel A in
either DIMM 0 or DIMM 1 of channel B (see
Figure 16).
Channel A
256 MB, 533 MHz
DIMM 0
256 MB, 533 MHz
DIMM 1
Channel B
512 MB, 533 MHz
DIMM 0
DIMM 1
Figure 16. Dual Configuration Example 3
NOTE
All other memory configurations will result in single channel memory operation.

Intel D945GTP Specifications

General

Form Factor	ATX
Processor Support	Intel Pentium 4, Pentium D, Celeron D
Socket Type	LGA 775
Memory Type	DDR2
Memory Slots	4
Maximum Memory	4 GB
Graphics	Intel GMA 950
Audio	Intel High Definition Audio
Ethernet	10/100/1000 Mbps
Expansion Slots	1 x PCI Express x16, 3 x PCI Express x1, 3 x PCI
USB Ports	8 x USB 2.0
Chipset	Intel 945G Express
Storage Interfaces	4 x SATA 3.0 Gb/s, 1 x PATA
