Intel D945GTP User Manual

Installing and Replacing Desktop Board Components
33
4. Remove the plastic protective socket cover from the load plate (see Figure 9, E). Do not
discard the protective socket cover. Always replace the socket cover if the processor is
removed from the socket.
OM17228
E
Figure 9. Remove the Protective Socket Cover
5. Remove the processor from the protective processor cover. Hold the processor only at the
edges, being careful not to touch the bottom of the processor (see
Figure 10). Do not discard
the protective processor cover. Always replace the processor back to the package if the
processor is removed from the socket.
OM17213
Figure 10. Remove the Processor from the Protective Processor Cover/Do Not Touch

Intel D945GTP Specifications

General

Form Factor	ATX
Processor Support	Intel Pentium 4, Pentium D, Celeron D
Socket Type	LGA 775
Memory Type	DDR2
Memory Slots	4
Maximum Memory	4 GB
Graphics	Intel GMA 950
Audio	Intel High Definition Audio
Ethernet	10/100/1000 Mbps
Expansion Slots	1 x PCI Express x16, 3 x PCI Express x1, 3 x PCI
USB Ports	8 x USB 2.0
Chipset	Intel 945G Express
Storage Interfaces	4 x SATA 3.0 Gb/s, 1 x PATA
