Intel D975XBX Product Guide

Desktop Board Features
15
Related Links
Go to the following link or pages for more information about:
• Audio drivers and utilities
http://support.intel.com/support/motherboards/desktop/
• Installing the front panel audio adapter, page 44 in Chapter 2
Input/Output (I/O) Controller
The super I/O controller features the following:
• One serial port
• One parallel port with Extended Capabilities Port (ECP) and Enhanced Parallel Port
(EPP) support
• Serial IRQ interface compatible with serialized IRQ support for PCI systems
• PS/2-style mouse and keyboard interfaces
• Interface for one 1.2 MB, 1.44 MB, or 2.88 MB diskette drive
• Intelligent power management, including a programmable wake up event interface
• PCI power management support
LAN Subsystem
The LAN, with the Intel 82801GH I/O Controller Hub, provides a Fast PCI LAN subsystem. The
LAN subsystem provides the following functions:
• Intel 82573V or 82573L Ethernet LAN supporting 10/100/1000 Mbit/sec
• Support for RJ-45 connector with status indicator LEDs
• Configurable EEPROM that contains the MAC address
LAN Subsystem Software
For LAN software and drivers, refer to the D975XBX link on Intel’s World Wide Web site at:
http://support.intel.com/support/motherboards/desktop

Intel D975XBX Specifications

General

Chipset	Intel 975X
Socket	LGA 775
Memory Type	DDR2
Memory Slots	4
Maximum Memory	8 GB
Form Factor	ATX
RAID Support	RAID 0, 1, 5, 10
USB Ports	8 x USB 2.0
Supported Processors	Intel Pentium 4, Pentium D, Core 2 Duo
Memory Speed	533/667 MHz
Expansion Slots	2 x PCI Express x16, 1 x PCI Express x4, 2 x PCI
Storage Interfaces	4 x SATA 3Gb/s, 1 x PATA
Audio	Intel High Definition Audio
LAN	Gigabit Ethernet
