Intel Desktop Board D975XBX Product Guide
28
4. Remove the protective socket cover from the load plate. Do not discard the protective socket
cover. Always replace the socket cover if the processor is removed from the socket (see
Figure 8, E).
OM19019
E
Figure 8. Remove the Protective Socket Cover
5. Remove the processor from its protective cover. Hold the processor only at the edges, being
careful not to touch the bottom of the processor (see Figure 9). Do not discard the protective
processor cover. Always replace the processor cover if the processor is removed from the
socket.
OM19016
Figure 9. Remove the Processor from the Protective Processor Cover

Intel D975XBX Specifications

General

Chipset	Intel 975X
Socket	LGA 775
Memory Type	DDR2
Memory Slots	4
Maximum Memory	8 GB
Form Factor	ATX
RAID Support	RAID 0, 1, 5, 10
USB Ports	8 x USB 2.0
Supported Processors	Intel Pentium 4, Pentium D, Core 2 Duo
Memory Speed	533/667 MHz
Expansion Slots	2 x PCI Express x16, 1 x PCI Express x4, 2 x PCI
Storage Interfaces	4 x SATA 3Gb/s, 1 x PATA
Audio	Intel High Definition Audio
LAN	Gigabit Ethernet
