Intel D975XBX User Manual

Technical Reference
59
Table 17. Component-side Connectors Shown in Figure 19
Item/callout
from Figure 19 Description
A
Auxiliary rear fan connector
B
PCI Conventional bus add-in card connector 2
C
PCI Express x16 (electrical x4) bus add-in card connector
D
ATAPI CD-ROM connector (optional)
E
PCI Conventional bus add-in card connector 1
F
Secondary PCI Express x16 (electrical x8) bus add-in card connector
G
Front panel audio connector
H
Primary PCI Express x16 (electrical x16 or x8) bus add-in card connector
I
Rear chassis fan connector
J Auxiliary PCI Express Graphics Power Connector (optional)
K
Processor power connector
L
Processor fan connector
M
Main power connector
N
Diskette drive connector
O
Parallel ATA IDE connector
P
Serial ATA connector 2 (ICH7-R/ICH7-DH RAID)
Q
Serial ATA connector 3 (ICH7-R/ICH7-DH RAID)
R
Chassis intrusion connector
S
Front chassis fan connector
T
Serial ATA connector 0 (ICH7-R/ICH7-DH RAID)
U
Serial ATA connector 1 (ICH7-R/ICH7-DH RAID)
V
Auxiliary front panel power LED connector
W
Front panel USB connector
X
Front panel USB connector
Y
Front panel IEEE-1394a connector [blue] (optional)
Z
Serial ATA connector 7 (Discrete RAID) (optional)
AA
Serial ATA connector 6 (Discrete RAID) (optional)
BB
Serial ATA connector 5 (Discrete RAID) (optional)
CC
Serial ATA connector 4 (Discrete RAID) (optional)
DD
SCSI hard drive activity indicator LED connector (optional)
EE
Front panel connector
