Intel Desktop Board DB75EN Technical Product Specification
22
1.5 Intel
®
B75 Express Chipset
Intel B75 Express Chipset with Intel Flexible Display Interconnect (Intel FDI) and
Direct Media Interface (DMI) interconnect provides interfaces to the processor and the
display, USB, SATA, LPC, LAN, and PCI Express interfaces. The Intel B75 Express
Chipset is a centralized controller for the board’s I/O paths.
For information about Refer to
The Intel B75 chipset http://www.intel.com/products/desktop/chipsets/index.htm
Resources used by the chipset Chapter 2
1.5.1 Direct Media Interface (DMI)
Direct Media Interface (DMI) is the chip-to-chip connection between the processor and
PCH. This high-speed interface integrates advanced priority-based servicing allowing
for concurrent traffic and true isochronous transfer capabilities.
1.5.2 Display Interfaces
Display is divided between the processor and the PCH. The processor houses the
memory interface, display planes, and pipes while the PCH has transcoder and display
interface or ports.
The PCH receives the display data over Intel FDI and transcodes the data as per the
display technology protocol and sends the data through the display interface.
1.5.2.1 Intel
®
Flexible Display Interconnect (Intel
®
FDI)
Intel FDI connects the display engine in the processor with the display interfaces on
the PCH. The display data from the frame buffer is processed in the display engine of
the processor and sent to the PCH over the Intel FDI where it is transcoded as per the
display protocol and driven to the display monitor.
1.5.2.2 Analog Display (VGA)
The VGA port supports analog displays. The maximum supported resolution is 2048 x
1536 (QXGA) at a 75 Hz refresh rate. The VGA port is enabled for POST whenever a
monitor is attached, regardless of the DVI-D connector status.
1.5.2.3 Digital Visual Interface (DVI-D)
The DVI-D port supports only digital DVI displays. The maximum supported resolution
is 2048 x 1536 at 75 Hz refresh (QXGA). The DVI-D port is compliant with the DVI 1.0
specification.
