Intel Desktop Board DB75EN Technical Product Specification
46
Table 12 lists the component-side connectors and headers identified in Figure 11.
Table 12. Component-side Connectors and Headers Shown in Figure 11
Item/callout f
rom Figure 11 Description
A Conventional PCI add-in card connector
B Conventional PCI add-in card connector
C PCI Express x1 add-in card connector
D PCI Express x16 add-in card connector
E 12 V processor core voltage connector (2 x 2 pin)
F Rear chassis fan header
G Processor fan header
H Front chassis fan header
I Chassis intrusion header
J LPC Debug header
K TPM header
L Main power connector (2 x 12)
M Intel MEBX reset header
N SATA 6.0 Gb/s connector (blue)
O eSATA 3.0 Gb/s connector (red)
P Alternate front panel power/sleep LED header
Q Front panel header
R SATA 3.0 connectors (black)
S Front panel USB 3.0 connector (blue)
T Front panel USB 2.0 header
U Front panel USB 2.0 header
V Serial port header
W S/PDIF out header
X Front panel audio header
Y Internal mono speaker header

Intel DB75EN Specifications

General

Chipset	Intel B75
Socket	LGA 1155
Memory Slots	4
Max Memory	32 GB
Memory Type	DDR3
PCIe x16 Slots	1
PCIe 2.0 x1 Slots	2
PCI Slots	1
SATA 3Gb/s Ports	5
SATA 6Gb/s Ports	1
USB 3.0 Ports	4
USB 2.0 Ports	8
Video Outputs	VGA, DVI-D
LAN	Intel 82579V
Form Factor	Micro ATX
Audio	Realtek ALC888S 8-Channel High Definition Audio CODEC
