Intel DB75EN User Manual

iii
Board Identification Information
Basic Desktop Board DB75EN Identification Information
AA Revision BIOS Revision Notes
G39650-300 ENB7510H.86A.0017 1,2
Notes:
1. The AA number is found on a small label on the component side of the board.
2. The B75 processor used on this AA revision consists of the following component:
Device Stepping S-Spec Numbers
Intel B75 Express Chipset A1 SLJ85
Specification Changes or Clarifications
Table 1 indicates the Specification Changes or Specification Clarifications that apply to
the Intel
®
Desktop Board DB75EN.
Table 1. Specification Changes or Clarifications
Date Type of Change Description of Changes or Clarifications
June 2012 Spec Clarification Removed references to RAID support and replaced with
SATA ACHI support.
Errata
Current characterized errata, if any, are documented in a separate Specification
Update. See http://developer.intel.com/products/desktop/motherboard/index.htm
for the latest documentation.

Intel DB75EN Specifications

General

Chipset	Intel B75
Socket	LGA 1155
Memory Slots	4
Max Memory	32 GB
Memory Type	DDR3
PCIe x16 Slots	1
PCIe 2.0 x1 Slots	2
PCI Slots	1
SATA 3Gb/s Ports	5
SATA 6Gb/s Ports	1
USB 3.0 Ports	4
USB 2.0 Ports	8
Video Outputs	VGA, DVI-D
LAN	Intel 82579V
Form Factor	Micro ATX
Audio	Realtek ALC888S 8-Channel High Definition Audio CODEC
