Intel Desktop Board DB75EN Technical Product Specification
50
2.2.2.2 Add-in Card Connectors
The board has the following add-in card connectors:
• One PCI Express x16 (3.0/2.x/1.x)
• One PCI Express x1 (2.x/1.x)
• Two Conventional PCI (rev 2.3)
Note the following considerations for the Conventional PCI bus connectors:
• The Conventional PCI bus connectors are bus master capable.
• SMBus signals are routed to the Conventional PCI bus connectors. This enables
Conventional PCI bus add-in boards with SMBus support to access sensor data on
the desktop board. The specific SMBus signals are as follows:
 The SMBus clock line is connected to pin A40.
 The SMBus data line is connected to pin A41.
NOTE
PCI Express 3.0 is only supported by 3
rd
generation Intel Core processor family
processors.

Intel DB75EN Specifications

General

Chipset	Intel B75
Socket	LGA 1155
Memory Slots	4
Max Memory	32 GB
Memory Type	DDR3
PCIe x16 Slots	1
PCIe 2.0 x1 Slots	2
PCI Slots	1
SATA 3Gb/s Ports	5
SATA 6Gb/s Ports	1
USB 3.0 Ports	4
USB 2.0 Ports	8
Video Outputs	VGA, DVI-D
LAN	Intel 82579V
Form Factor	Micro ATX
Audio	Realtek ALC888S 8-Channel High Definition Audio CODEC
