Intel Desktop Board DB75EN Technical Product Specification
58
2.6 Electrical Considerations
2.6.1 Power Supply Considerations
CAUTION
The +5 V standby line from the power supply must be capable of providing adequate
+5 V standby current. Failure to do so can damage the power supply. The total
amount of standby current required depends on the wake devices supported and
manufacturing options.
Additional power required will depend on configurations chosen by the integrator.
The power supply must comply with the indicated parameters of the ATX form factor
specification.
• The potential relation between 3.3 V DC and +5 V DC power rails
• The current capability of the +5 VSB line
• All timing parameters
• All voltage tolerances
For example, for a high power system consisting of a supported 95 W processor (see
Section 1.3 on page 16 for a list of supported processors), 4 GB DDR3 RAM, one high
end video card, one hard disk drive, one optical drive, and all board peripherals
enabled, the minimum recommended power supply is 460 W. Table 32 lists possible
recommended power supply current rail values.
Table 32. Recommended Power Supply Current Values (High Power)
Output Voltage 3.3 V 5 V 12 V1 12 V2 -12 V 5 VSB
Current 22 A 20 A 20 A 20 A 0.3 A 2.5 A
For example, for a low power system consisting of a supported 45 W processor (see
Section 1.3 on page 16 for a list of supported processors), 2 GB DDR3 RAM, integrated
graphics, one SSD, one optical drive, and no extra onboard peripherals enabled, the
minimum recommended power supply is a 320 W. Table 33 lists possible
recommended power supply current rail values. Note: If the correct power supply and
system configuration is used, a smaller power supply will work.
Table 33. Recommended Power Supply Current Values (Low Power)
Output Voltage 3.3 V 5 V 12 V1 12 V2 -12 V 5 VSB
Current 20 A 20 A 15 A 15 A 0.3 A 1.5 A
For information about Refer to
Selecting an appropriate power supply http://support.intel.com/support/motherboards/desktop/sb
/CS-026472.htm

Intel DB75EN Specifications

General

Chipset	Intel B75
Socket	LGA 1155
Memory Slots	4
Max Memory	32 GB
Memory Type	DDR3
PCIe x16 Slots	1
PCIe 2.0 x1 Slots	2
PCI Slots	1
SATA 3Gb/s Ports	5
SATA 6Gb/s Ports	1
USB 3.0 Ports	4
USB 2.0 Ports	8
Video Outputs	VGA, DVI-D
LAN	Intel 82579V
Form Factor	Micro ATX
Audio	Realtek ALC888S 8-Channel High Definition Audio CODEC
