Error Messages and Beep Codes

Table 47. Port 80h POST Codes (continued)

Port 80 Code Progress Code Enumeration

Removable Media

0xB8 Resetting removable media

0xB9 Disabling removable media

0xBA Detecting presence of a removable media (IDE, CDROM detection

etc.)

0xBB Enabling/configuring a removable media

DXE Core

0xE4 Entered DXE phase

BDS

0xE7 Waiting for user input

0xE8 Checking password

0xE9 Entering BIOS setup

0xEB Calling Legacy Option ROMs

Runtime Phase/EFI OS Boot

0xF8 EFI boot service ExitBootServices ( ) has been called

0xF9 EFI runtime service SetVirtualAddressMap ( ) has been called

Questions and Answers:

Need help?

Do you have a question about the Intel DB75EN and is the answer not in the manual?

General

Chipset	Intel B75
Socket	LGA 1155
Memory Slots	4
Max Memory	32 GB
Memory Type	DDR3
PCIe x16 Slots	1
PCIe 2.0 x1 Slots	2
PCI Slots	1
SATA 3Gb/s Ports	5
SATA 6Gb/s Ports	1
USB 3.0 Ports	4
USB 2.0 Ports	8
Video Outputs	VGA, DVI-D
LAN	Intel 82579V
Form Factor	Micro ATX
Audio	Realtek ALC888S 8-Channel High Definition Audio CODEC
