Desktop Board Features
13
Table 2. Intel Desktop Board DG41TX Components
Label Description
A Front panel audio header
B PCI bus connector
C PCI bus connector
D PCI Express x1 connector
E PCI Express x16 connector
F Speaker
G Back panel connectors
H 12 V processor core voltage connector (2 x 2 pin)
I Rear chassis fan header
J Battery
K Processor socket
L Processor fan header
M DDR3 Channel A DIMM socket
N DDR3 Channel B DIMM socket
O Diskette drive connector
P Parallel ATA (PATA) connector
Q Main power connector (2 x 12 pin)
R Standby power LED
S Serial ATA (SATA) connectors (4)
T Front chassis fan header
U Chassis intrusion header
V BIOS configuration jumper block
W Front panel USB 2.0 headers
X Front panel header
Y Alternate front panel power LED header
Z Serial header
AA Intel HD Audio Link header
BB S/PDIF header
