Intel DG41TX - PME# Signal Wake-Up Support; Wake from Serial; Wake from USB; Location of the +5 V Standby Power Indicator

Intel Desktop Board DG41TX Product Guide
26
Figure 3. Location of the +5 V Standby Power Indicator
For more information on standby current requirements for the Desktop Board, refer to
the Technical Product Specification at
http://www.intel.com/support/motherboards/desktop
.
Wake from USB
NOTE
Wake from USB requires the use of a USB peripheral that supports Wake from USB.
USB bus activity wakes the computer from an ACPI S1 or S3 state.
Wake from Serial
Serial bus activity wakes the computer from an ACPI S1 or S3 state.
PME# Signal Wake-up Support
When the PME# signal on the PCI bus is asserted, the computer wakes from an
ACPI S1, S3, S4, or S5 state.
