Intel DG41TX - Desktop Board Features

9
1 Desktop Board Features
This chapter briefly describes the features of Intel
®
Desktop Board DG41TX. Table 1
summarizes the major features of the board.
Table 1. Feature Summary
Form Factor
microATX (243.84 millimeters [9.60 inches] x 243.84 millimeters
[9.60 inches])
Processor Support for an Intel
®
processor in the LGA775 package
Main Memory
• Two 240-pin, DDR3 SDRAM Dual Inline Memory Module (DIMM)
sockets
• 1333 (over clocked)/1066/800 MHz single or dual channel DDR3
SDRAM interface
• Support for up to 4 GB of main memory
Chipset • Intel
®
G41 Express Chipset** consisting of:
• Intel G41 Express Chipset** Graphics and Memory Controller Hub
(GMCH)
• Intel
®
82801G I/O Controller Hub (ICH7)
Integrated Graphics
• Intel G41 Express Chipset** with
Intel
®
Graphics Media Accelerator
X4500 (Intel
®
GMA X4500)
• Support for dual independent displays via VGA and DVI-D ports
External Graphics
• One PCI Express* 2.0 x16 connector
• One PCI Express 1.1 x1 connector
• Two PCI* connectors
Audio Onboard subsystem, featuring:
• Realtek* ALC888VC audio codec
• 8-channel (6 + 2) audio support:
― Independent 6-channel (5.1) back panel audio streams
― 2-channel stereo front panel audio streams via an onboard
header
• Intel
®
High Definition Audio (Intel
®
HD Audio) interface with
support for AC ’97 Audio
• Onboard 4-pin S/PDIF output header
• Intel HD Audio Link header
Expansion
Capabilities
• One PCI Express 2.0 x16 connector
• One PCI Express 1.1 x1 connector
• Two PCI connectors
Legacy I/O Support Legacy I/O controller that provides:
• One serial port via an onboard header
• Two back panel PS/2 ports
continued
