Intel Desktop Board DG41TX Product Guide
18
Go to the following locations for more information about:
• Audio drivers and utilities http://www.intel.com/support/motherboards/desktop
• Location of the onboard audio headers, Figure 21 on page 47
• The location and description of the
back panel audio connectors, Figure 22 on
page 51
Table 3 lists the supported functions for the front panel and back panel audio jacks.
Table 3. Back Panel and Front Panel Audio Jack Retasking Support
Jack Mic Headphones
Line/Front
Speaker
Line
In
Rear
Surround
Center/
Subwoofer
Front Panel
Green - Control Panel Default - - -
Pink Default - - - - -
Back Panel
Blue - - - Default Control Panel -
Green - Control Panel Default - - -
Pink Default - - - - Control Panel
Legacy Input/Output (I/O) Controller
The legacy I/O controller provides the following:
• One serial port interface via an onboard header
• Two PS/2 ports for keyboard and mouse support
• Serial IRQ interface compatible with serialized IRQ support for PCI systems
• Intelligent power management, including a programmable wake up event interface
• PCI power management support
