英特尔台式机主板 DH55PJ 产品指南
18
3. LAN 连接器 LED 指示灯
LED 指示灯
LED 指示灯
颜色
LED 指示灯
状态
表示
A(连接/活动) 熄灭 未建立 LAN 连接
绿色
亮起 已建立 LAN 连接
闪烁 LAN 正处于活动状态
不适用 熄灭 每秒 10 Mb 的数据速率
绿色 亮起 每秒 100 Mb 的数据速率
B(连接速度)
黄色 亮起 每秒 1000 Mb 的数据速率
USB 2.0 支持
本主板最多支持十二个 USB 2.0 端口,分别由 PCH 中允许使用 EHCI 兼容驱动程序的两 EHCI
主控制器提供。
端口布置如下:
六个端口通过叠层式背面板连接器实
六个前面板端口通过三个双端口内置接头连接器实现
获得 USB 2.0 支持需要操作系统和驱动程序都完全支持 USB 2.0 传输速率
串行 ATA 支持
本主板通过 PCH 提供四个内置 SATA 连接器。
扩展功能
英特尔台式机主板 DH55PJ 提供以下各项扩展功能:
一个 PCI Express 2.0 x16 端口
两个 PCI Express 2.0 x1 端口
一个 PCI 总线接口
