安装和更换台式机主板组件
43
前面板音频接头连接器
前面板音频接头连接器,如图 20 中的 A 所示,支持英特尔高保真 (HD) 音频和 AC ’97 音频。
4 列出了高保真音频的引脚分配和信号名称,而表 5 则列出了 AC ’97 音频的引脚分配和信号
名称。
4. 前面板英特尔高保真音频信号名称
引脚 信号名称 引脚 信号名称
1
PORT 1L (Microphone)(话筒)
2
GND(接地)
3
PORT 1R (Microphone)(话筒)
4 PRESENCE#
5
PORT 2R (Headphone)(耳机)
6 SENSE1_RETURN
7 SENSE_SEND 8
KEY(无引脚)
9
PORT 2L (Headphone)(耳机)
10 SENSE2_RETURN
5. 前面板 AC ’97 音频接头连接器信号名称
引脚 信号名称 引脚 信号名称
1
MIC(话筒)
2 AUD_GND
3 MIC_BIAS 4 AUD_GND
5 FP_OUT_R 6 FP_RETURN_R
7 AUD_5V 8
KEY(无引脚)
9 FP_OUT_L 10 FP_RETURN_L
内置单声道扬声器接头连接器
20 中的 B 显示了内置单声道扬声器接头连接器。表 6 列出了内置单声道扬声器接头连接器的
引脚分配和信号名称。
6. 内置单声道扬声器接头连接器
引脚 信号名称
1
2 +
