安装和更换台式机主板组件
35
安装和拆卸系统内存
注释
为了完全符合所有适用的英特尔 SDRAM 内存规范,应在本台式机主板上安装支持串行设备检
(SPD) 数据结构的 DIMM 内存模块。
本台式机主板具备两个 240 DDR3 DIMM 插槽,分别提供通道 A 和通道 B。要获得最优的
双通道性能,请安装速度和容量均相互匹配的一对 DIMM(参见图 14)。
14. 双通道内存配置示例
注释
如采用任何其它方式配置内存,均会导致单通道内存操作。
