Intel DQ35JO - Desktop Board Executive Series Motherboard

Desktop Board Features
13
Table 2. Desktop Board DQ35JO Components
Label Description
A Front panel audio header
B Speaker
C PCI bus connector
D PCI Express x1 connector 2
E Battery
F PCI Express x1 connector 1
G PCI Express x16 connector
H Rear chassis fan header (3-pin)
I Back panel connectors
J 12 V processor core voltage connector (2 x 2 pin)
K Processor socket
L Processor fan header (4-pin)
M Serial header
N Main power connector (2 x 12 pin)
O DDR2 DIMM 0 sockets
P DDR2 DIMM 1 sockets
Q Front panel header
R Alternate front panel power LED header
S Chassis intrusion header
T BIOS configuration jumper block
U Front chassis fan header (3-pin)
V Serial ATA connectors
W External SATA (eSATA) connector
X High-speed USB 2.0 header 2
Y High-speed USB 2.0 header 3
Z High-speed USB 2.0 header 1
AA IDE connector
BB IEEE 1394a header
CC High Definition Audio Link header
