Installing and Replacing Desktop Board Components
51
Connecting to the HD Audio Link Header
See Figure 24, A for the location of the HD Audio Link header. Table 6 shows the pin
assignments for the header.
Table 6. HD Audio Link Header Signal Names
Pin Signal Name Pin Signal Name
1 BCLK 2 Ground
3 RST# 4 3.3 Vcc
5 SYNC 6 Ground
7 SDO 8 3.3 Vcc
9 SDI0 10 +12 V
11 SDI1 12 Key
13 No Connection 14 3.3 V STBY
15 No Connection 16 Ground
Connecting to the IEEE 1394a Header
See Figure 24, C for the location of the IEEE 1394a header. Table 7 shows the pin
assignments for the header.
Table 7. IEEE 1394a Signal Header Names
Pin Signal Name Pin Signal Name
1 TPA1+ 2 TPA1-
3 Ground 4 Ground
5 TPA2+ 6 TPA2-
7 +12 V 8 +12 V
9 Key (no pin) 10 Ground
Installing a Front Panel Audio Solution for Intel
®
High
Definition Audio
Figure 24, B shows the location of the front panel audio header. Table 8 shows the pin
assignments for the front panel audio header.
Table 8. Front Panel Intel High Definition Audio Header Signal Names
Pin Signal Name Pin Signal Name
1 PORT 1L 2 GND
3 PORT 1R 4 PRESENCE#
5 PORT 2R 6 SENSE1_RETURN
7 SENSE_SEND 8 KEY (no pin)
9 PORT 2L 10 SENSE2_RETURN
