6-30 PRO/100 LAN+Modem PC Card User’s Guide
S37=5 Attempt to connect at 1200bps
S37=6 Attempt to connect at 2400bps
S37=7 Attempt to connect at 4800bps
S37=8 Attempt to connect at 7200bps
S37=9 Attempt to connect at 9600bps
S37=10 Attempt to connect at 12000bps
S37=11 Attempt to connect at 14400bps
S37=12 Attempt to connect at 16800bps
S37=13 Attempt to connect at 19200bps
S37=14 Attempt to connect at 21600bps
S37=15 Attempt to connect at 24000bps
S37=16 Attempt to connect at 26400bps
S37=17 Attempt to connect at 28800bps
S37=18 Attempt to connect at 31200bps
S37=19 Attempt to connect at 33600bps
S40 ETC Startup Autorating
S40=0 Start up with normal autorating (default)
S40=1 Start up at initial rate of 4800 or below
S40=2 Start up at initial rate of 9600 or below
S42 Auto Rate
V.32bis and V.22bis auto rate is disabled. Retrain operation is disabled or
enabled in date mode, and fallback is disabled in data mode.
S42=0 Auto rate disabled
S42=1 Auto rate enabled (default)
S43 Auto Mode
V.32bis startup auto mode operation disabled.
S43=0 Auto mode disabled
S43=1 Auto mode enabled (default)

Intel ETHEREXPRESS PRO/100 Specifications

General

Device Type	Network adapter
Form Factor	Plug-in card
Data Link Protocol	Ethernet, Fast Ethernet
Data Transfer Rate	100 Mbps
Compliant Standards	IEEE 802.3, IEEE 802.3u
Connector Type	RJ-45
Bus Type	PCI
Chipset	Intel 82557
Full Duplex Support	Yes
Wake-on-LAN Support	Yes
Ports	1 x RJ45
Data Rate	10 Mbps / 100 Mbps
Operating Systems Supported	Linux, Windows
