Intel ETHEREXPRESS PRO/100 User Manual

3-10 PRO/100 LAN+Modem PC Card User’s Guide
The registry parameters are as follows:
Keyword Default Valid Values
BUSNUMBER 0
BUSTYPE 0X1
DIRECTENABLE 0 0-1
EARLYTRANSMIT 0X1 0-1
FULLDUPLEX 0 0-1
FUNCTIONENABLE 0 0-2
INTERRUPTNUMBER 0X5 3,4,5,7,8,9,A,B,F
IOBASEADDRESS 0X2E8 3F8,2F8,3E8,2E8
IOBASEADDRESS_1 0X320 0X200 - 0X3D0
IOLENGTH 0X07
IOLENGTH_1 0XF
LINESPEED 0 0-2
LINKINTEGRITY 0X1 0-1
MEMORYMAPPEDBASEADDRESS 0XD6000 A2000-FF000
MEMORYMAPPEDSIZE 0X1000
MODE 0 0-1
MODEMFUNCTION 0X01 0-1
NETWORKADDRESS
PCCARDATTRIBUTEMEMORYADDRESS 0XD4000 A0000 - FE000
PCCARDATTRIBUTEMEMORYOFFSET 0XF000
PCCARDATTRIBUTEMEMORYSIZE 0X2000
PCCARDMEMORYWINDOWOFFSET 0
PCMCIA 1 0-1
PLATFORMTYPE 0 0-1
TRANSMITBUFFERSIZE 0X1C00 0X0400-0X1E800

Intel ETHEREXPRESS PRO/100 Specifications

General

Device Type	Network adapter
Form Factor	Plug-in card
Data Link Protocol	Ethernet, Fast Ethernet
Data Transfer Rate	100 Mbps
Compliant Standards	IEEE 802.3, IEEE 802.3u
Connector Type	RJ-45
Bus Type	PCI
Chipset	Intel 82557
Full Duplex Support	Yes
Wake-on-LAN Support	Yes
Ports	1 x RJ45
Data Rate	10 Mbps / 100 Mbps
Operating Systems Supported	Linux, Windows
