Intel ETHEREXPRESS PRO/100 User Manual

Windows 3.x/MS-DOS Installation 4-55
Type File Name Configuration Method
ODI M16BODI.COM reads NET.CFG configuration file
NDIS2 M16BNDIS.EXE reads PROTOCOL.INI configuration file
Packet M16BPD.EXE uses COMMAND LINE parameters
Test M16BTEST.EXE uses COMMAND LINE parameters
The default resources used by the PRO/100 PC Card when no other
setting is stated are:
MEMORY AUTO
IRQ AUTO
IOADDRESS (NDIS) AUTO
PORT (ODI) AUTO
Troubleshooting combinations for driver configuration without Card and
Socket Services:
TRIAL MEM INT IOADDRESS WORDSIZE
Default D2000 5 320 16
1 CC000 5 320 16
2 D2000 10 320 16
3 CC000 10 320 16
4 D2000 11 320 16
5 CC000 11 320 16
6 D2000 15 320 16
7 CC000 15 320 16
8 D2000 5 340 8
9 CC000 5 340 8
10 D2000 10 340 8
11 CC000 10 340 8
12 D2000 11 340 8
13 CC000 11 340 8
14 D2000 15 340 8
15 D2000 15 340 8

Intel ETHEREXPRESS PRO/100 Specifications

General

Device Type	Network adapter
Form Factor	Plug-in card
Data Link Protocol	Ethernet, Fast Ethernet
Data Transfer Rate	100 Mbps
Compliant Standards	IEEE 802.3, IEEE 802.3u
Connector Type	RJ-45
Bus Type	PCI
Chipset	Intel 82557
Full Duplex Support	Yes
Wake-on-LAN Support	Yes
Ports	1 x RJ45
Data Rate	10 Mbps / 100 Mbps
Operating Systems Supported	Linux, Windows
