1.Introduction
Keyboard
Full Size Multi Full Color LED Keyboard (with numeric key-
pad)
Or
(Factory Option) Full Size Full Color “Per Key” LED Key-
board (with numeric keypad)
Storage
(Factory Option) Two M.2 SSDs:
One M.2 PCIe Gen4 x4 Solid State Drive (SSD)*
One M.2 SATA/PCIe Gen3 x4 Solid State Drive (SSD)*
*Supporting RAID Level 0/1 with two PCIe SSDs (PCIe Gen3
x4)
Audio
High Definition Audio Compliant Interface
S/PDIF Digital Output
Built-In Array Microphone
Two Speakers
Sound Blaster Atlas
M.2 Slots
Slot 1 for Combo WLAN and Bluetooth Module
Slot 2 for SATA or PCIe Gen3 x4 SSD
Slot 3 for PCIe Gen4 x4 SSD
Communication
1.0M HD Webcam
Built-In 10/100/1000Mb Base-TX Ethernet LAN
WLAN/ Bluetooth M.2 Modules:
(Factory Option) Intel® Dual Band Wi-Fi 6 AX200, 2x2 AX
Wireless LAN + Bluetooth
(Factory Option) Intel® Dual Band Wi-Fi 6 AX201, 2x2 AX
Wireless LAN + Bluetooth
(Factory Option) Intel® Dual Band Wireless-AC 9560, 2x2
AC Wireless LAN + Bluetooth
(Factory Option) Killer™ Dual Band
Wi-Fi 6 AX1650i , 2x2 AX Wireless LAN + Bluetooth
Interface
One Thunderbolt 4 Port
Three USB 3.2 Gen 1 Type-A Ports (Including one AC/DC
Powered USB Port)
One Mini DisplayPort 1.4
One HDMI-Out Port
One 2-In-1 Audio Jack (Microphone / S/PDIF Optical)
One 2-In-1 Audio Jack (Headphone / Microphone)
One RJ-45 LAN
Jack
One DC-In Jack
Features
Intel® Optane™ Technology
Virtual Reality Ready
Windows® Mixed Reality Compatible
Pantone Certificate*
*These features apply to some individual model designs
within this series (check with your distributor/supplier for
details).
Environmental Spec
Temperature
Operating: 5°C - 35°C
Non-Operating: -20°C - 60°C
Relative Humidity
Operating: 20% - 80%
Non-Operating: 10% - 90%
Power
Embedded 3 Cell Polymer Battery Pack, 73WH
Full Range AC/DC Adapter
AC Input: 100 - 240V, 50 - 60Hz
DC Output: 19.5V, 9.23A (180W)
Dimensions & Weight
357.5mm (w) * 238mm (d) * 19.8mm (h)
1.99kg (Barebone with 62WH Battery)
