Disassembly
Removing and Installing the Keyboard 2 - 7
2.Disassembly
Removing and Installing the Keyboard
Keyboard Removal Procedure
1. Turn off the computer, remove the battery (page 2 - 5).
2. The keyboard adhesive mylar will be visible at point on the computer. Pull the adhesive mylar out to release
the keyboard (Figure 3a).
3. Open it up with the LCD on a flat surface before pressing at point
to release the keyboard module (use the spe-
cial eject stick to do this) while releasing the keyboard in the direction of the arrow
as shown (Figure 3b).
1
2
3
4
5
a.
3
1
5
4
b.
2

4. Eject Stick
Figure 3
Keyboard Removal
a. Remove the adhesive
mylar from the keyboard.
b. Use a special eject stick
to push the keyboard out
while releasing the key-
board as shown.
