Disassembly
Removing the Battery 2 - 5
2.Disassembly
Removing the Battery
1. Turn off the computer, turn it over.
2. Remove screws
- (Figure 1a).
3. Carefully lift the bottom case
up in the direction of the arrow at point while holding the top case part of the
RJ-45 LAN jack
down (Figure 1b).
4. Remove the bottom case .
5. The battery will be visible at point on the computer (Figure 1c
).
1
12
13
14
15
13
16
Figure 1
Battery Removal
a. Remove the screws.
b. Lift the bottom case.
c. Locate the battery.

Screws
Note that screws
&
is using M2.5 X 8L.
1
4
2
a.
b.
c.
1
13
14
7
8
9
11
12
10
4
5
6
3
15
16
13

13. Bottom Case
•12 Screws
