1
2
3
6
4
5
7 8
Figure 8
Mainboard Bottom
Key Parts
1. GPU
2. CPU
3. PCH
4. Memory Slots
DDR4 SO-DIMM
5. KBC-ITE IT5570
6. Mini-Card
Connector (WLAN
Module)
7. Mini-Card
Connector (M.2
PCIE/Optane SSD
Module)
8. Mini-Card
Connector (M.2
PCIE/SATA SSD
Module)
Introduction
Mainboard Overview - Bottom (Key Parts) 1 - 9
1.Introduction
Mainboard Overview - Bottom (Key Parts)
