2 - 6 Removing the Battery
2.Disassembly
6. Carefully disconnect the cable , then remove screws - (Figure 2d). Note: make sure that SSD-2 (page
2 - 12) is not installed before removing screw .
7. Lift the battery off the computer (Figure 2e
).
8. Reverse the process to install a new battery (do not forget to replace all the screws and bottom cover).
Figure 2
Battery Removal
(cont’d.)
d. Disconnect the cable and
remove the screws.
e. Lift the battery off the
computer.
