Intel PC50HS User Manual

Disassembly
2 - 8 Removing and Installing the Keyboard
2.Disassembly
4. Carefully lift the keyboard up, being careful not to bend the keyboard ribbon cable . Disconnect the key-
board ribbon cable from the locking collar socket by using a flat-head screwdriver to pry the locking collar pins
away from the base (Figure 4c).
5. Carefully lift the keyboard off the computer (Figure 4d).
6
7
7
8
6
c.
d.
6
7
7
8
6
8
8
7

6. Keyboard
Figure 4
Keyboard Removal
(cont’d.)
c. Lift the keyboard up and
disconnect the keyboard
ribbon cable from the
locking collar socket.
d. Remove the keyboard.
