Intel SE7520BD2 User Manual

Server Board Features
Intel® Server Board SE7520BD2
1
1 Server Board Features
This chapter briefly describes the main features of the Intel
®
Server Board SE7520BD2, as well as
provides a photograph of the product, a list of the server board features, and diagrams showing the
location of important components and connections on the server board.
There are three SKUs available for the Intel® Server Board SE7520BD2.
Product Code PCI SCSI SATA Ethernet Intel® Light-
Guided
Diagnostics
USB
Connections
Intel® Server
Board
SE7520BD2
SCSI
1 - PCI Express* x8
1 - PCI Express* x4
1 - PCI-X* 133MHz
2 - PCI-X* 100MHz
1 - PCI 32-bit /
33MHz 5V
Two Ultra-
320/LVD
channels via
the LSI*
53C1030
SCSI
controller
Dual serial ATA
channels with
support for RAID 0
and 1.
One IDE connector
supporting two
ATA/100 IDE
channels.
Dual Gig Yes 5 (3 at rear of
board, 2 in
front)
Intel® Server
Board
SE7520BD2-V
1 - PCI Express* x4
1 - PCI-X* 133MHz
2 - PCI-X* 100MHz
1 - PCI 32-bit /
33MHz 5V
One Ultra-
320/LVD
channel via
either the
LSI*
53C1020 or
LSI*
53C1020A
SCSI
controller
Dual serial ATA
channels with
support for RAID 0
and 1.
One IDE connector
supporting two
ATA/100 IDE
channels.
Dual Gig No 4 (2 at rear of
board, 2 in
front)
Intel® Server
Board
SE7520BD2
1 - PCI Express* x8
1 - PCI Express* x4
1 - PCI-X* 133MHz
2 - PCI-X* 100MHz
1 - PCI 32-bit /
33MHz 5V
NA Dual serial ATA
channels with
support for RAID 0
and 1.
One IDE connector
supporting two
ATA/100 IDE
channels.
Dual Gig Yes 5 (3 at rear of
board, 2 in
front)
