Intellian V100 User Manual

v100 – Marine Satellite Communication System
118
5
BOW Offset Display current bow offset
6
DVB Information
Displays DVB tracking mode’s current tracking information.
- Frequency: displays tracking frequency.
- Symbol rate: displays symbol rate.
- NID: displays network ID.
- Verify type: displays verication typ
(AGC, DVB, DVB Decode)
7
NBD Information
Displays NBD tracking mode’s current tracking information.
- Frequency: displays tracking IF frequency.
- Bandwidth: displays detection bandwidth.
8
Local Frequency
Setting (MHz)
Displays current LNB’s local frequency and voltage
9
Satellite
Information
Displays current Antenna and ACU rmware versions and Satellite
Library version installed in the system.
- Antenna POL Version
(It will display "v-----" if there is no Pol Control Board installed.)
- Antenna Stabilizer Version
- Antenna PCU Version
- ACU Main Version
- Library Version
10
Azimuth
Animation
Shows a graphical representation of the current antenna position
to identify whether or not the antenna is aligned properly to the
target satellite or is in a block zone.
11
TX Enable
Displays whether or not the antenna is able to transmit the data.
The TX function will only be enabled (shows BLUE dot ) only if all of
the factors listed below shows “BLUE” dot. Exception: If “Use TX
Mute” is set as “NO”, the TX function will be enabled regardless of
which factor listed below shows “gray” dot or “red” dot.
- Enable Mode: antenna is not in SETUP mode.
- Blockage: antenna is not facing the predened block zone(s). -
Pointing: antenna is pointing to the target satellite.
- Modem Lock: satellite modem is sending a logic input to the
ACU to identify when the antenna tracks on the correct satellite.
- LNB Rotate: LNB is not rotating.
12
Tracking
Satellite
Displays current tracking mode.
- Satellite: displays satellite name.
- Longitude: displays satellite orbit position.
- Skew Offset: displays Skew offset.
- Tracking Method: displays current tracking mode (DVB/ NBD).
- RX Polarization: displays current RX polarization.
- TX Polarization displays current TX polarization.
13
Antenna
Information
Displays the product information
14
Information
- Control IP: Displays current IP that controls the ACU.
- Current IP: Displays current IP address.
- Refresh Rate: Displays screen refresh rate (default: 1 sec.)
- Refresh Disable: Displays time out.
The screen will not refresh once the time-out shows 0:00.
Exception: If the Refresh Disable Time is set to “OFF” in the
Network Setting page, then the clock will show “--:--“ and
system will keep monitoring all activities regardless of timeout.
- Wi-Fi : Displays Wi on/off switch
