Intellian V100 - Antenna Mounting Templates; Bow Direction

To Next Page

To Previous Page

v100 – Marine Satellite Communication System

Cable Entry

Hatch

Radome Bottom

Radome Hatch

ø44.5cm (17.5”)

BOW

Antenna Mounting Templates

The mounting holes must be in the exact same place as shown in the diagram

below.

Bow direction
