47
2.6.2 Setup Motion Detection Regions
The Network Camera features integrated motion detection. The camera does a
frame-by-frame comparison and then determines, based on the motion detection
window, sensitivity settings and threshold, whether or not a motion has occurred.
The motion detection does not use infrared. It requires a visible image in order to
function.
The camera supports three independent motion detection windows that can be
placed and resized individually.
Item Description
Region1
Region2
Region3
Click to activate the motion detection window. Once
clicked, you will see a rectangle appear on the screen.
Use the mouse to move the rectangle to a different
position or to resize it.
To Next Page
