8-2 LED Indicator
Use the following table to understand the meaning of the diagnostic LED’s
Display LED:
Input Voltage
Output Voltage
Output Current
Green LED Solid
Green LED Solid
Green LED Solid
Orange LED Slow Flash
Orange LED Slow Flash
Orange LED Solid
Orange LED Fast Flash
Orange LED Fast Flash
Orange LED Slow Flash
Red LED Slow Flash
Red LED Solid Flash
Orange LED Fast Flash
Red LED Fast Flash
Red LED Fast Flash
No light
Normal
Normal
C.V. & Float
Under Voltage Alarm
Under Voltage Alarm
C.V. & Absorpon
Over Voltage Alarm
Over Voltage Alarm
C.C. & Bulk
Under Voltage Protecon Shutdown
Short Circuit Protecon Shutdown
C.C. & De-rang
Over Voltage Protecon Shutdown
Over Voltage Protecon Shutdown
Charging OFF
LED1
LED2
LED3
Status
Status
Status
17
