Intellitec BBINT Series User Manual

Charging Curve with Battery Temperature Compensation
U Rer 20°C
-3.33mv / °C per cell
12Volt system : -10mv / 0.5 °C
Temperature compensation characteristic
(charge voltage versus temperature)
52°C
12.0
12.5
13.0
13.5
14.0
14.5
15.0
-20 -10 0 10 20 30 40 50 60
Batery temperature (°C)
Charging voltage (V)
14.8VDC
14.4VDC
14.0VDC
ABSORPTION
FL
O
A
T
14.2VDC
13.4VDC
13.8VDC
* If at - Absorption = 14.4V and Float = 13.8V20°C
6
- Fitting Kit k449 inc 8 Way Molex Mini Fit Jr including 30cm Terminated cables/tails.
- Battery Temperature Sensor (Not included, to be ordered separately) part no. APP-TEMP
Descripon Diagram
Temperature
Sensor
(Oponal)
unit:mm
3-2 Optional Accessories
12.5
58.5
11
22
2.5
14
Length : A
φ8.5
Length (max)
A 4600mm
Please refer to graph for adjusted temperature compensated values
1. Ignion/Enable (Acve HIGH)
2. BMS+ Enable (Acve High)
3. BMS- Enable (Acve Low)
4. Voltage Sensor + (0-17V)
5. Charging Relay Common
6. Charging Relay Normally Open
7. OTA Relay Common
8. OTA Relay Common
Loose Terminals
- Programming Cable (Part NO. K447). The programming cable is to be used in conjunction with
Intellitec’s battery to battery charger GUI, which is available to download at the hyperlink below:
https://www.intellitecmv.com/pages/downloads
part no.
APP-TEMP
