Intellitec BBINT Series User Manual

3-3 Features
• The converter can be fully programmed by DIP Switches or by RS-232 using
• Built-in battery rescue (pre-charging) function
• Compatible with Lead Acid, LiFePO4, Gel and AGM batteries
• High efficiency and high reliability
• Withstand 2G vibration test
• Advanced Protection Features
• Built-in Buck Boost Converter (12V to 12V)
• Voltage / Temperature Compensation with Battery Temperature Sensor (Optional)
- Input / Output Reversed Polarity Protection by fuse
- Input Over & Under Voltage Protection
- Output Over Voltage / Short Circuit Protection
- Internal Over Temperature Protection
3-4 Specification
MODEL
BBINT50A
OUTPUT
Rated Power
750W
Absorpon Voltage
DIP S1
0 : 14.4V ±1%
1 : 14.7V ±1%
Float Voltage
DIP S2
0 : 13.5V ±1%
1 : 13.8V ±1%
Recharge Voltage
DIP S3
0 : 12V ±1%
1 : 12.8V ±1%
Charge Current
DIP S4
0 : 100%
1 : De-Rang 50%
Charging Control
DIP S6 & S5
00 : Charger 1 : bulk->absorpon->float->recharge
01 : Charger 2 : bulk->absorpon->OFF->recharge
10 : Power Supply 1 : Constant Voltage by DIP S2
11 : Power Supply 2 : Constant Voltage by DIP S3
Level DIP S7
N/A
Baery Type
Lead Acid/LiFePO4/Gel/AGM/Program(DIP S8)
Fuse
35A x 2
INPUT
Voltage Range
10V ~ 17V ±1%
Efficiency (Max.)
92%
Parasic Curent
( Ignion OFF )
< 5mA
Type
Baery / Alternator / DC Source
Fuse
35A x 3
7
Intellitec MV GUI software BBINT50, downloadable from Intellitec MV Website
• Low temperature cut off and heater control for LifePo4 (requires temperature sensor)
