3-1 Dimensions
The BBINT50A charger converters a DC (battery) voltage to a regulated DC voltage. It can be used as a:
• 2-Stage battery charger or
• DC power supply.
The BBINT50A can only be used in installations with a negative ground.
Unit: mm
193 37
34
125
7
150
130
44
CN1 LIN
REMOTE
RS-232 TEMP.
0 1
S1
S2
S3
S4
S6
S7
S8
S5
OUT
IN
+
-
+
Input Voltage
Output Voltage
Output Current
BMS
Igni�on / Enable
Error
136.5
3. Product Description
4
• 3-Stage battery charger or
