Intellitec BBINT Series - Page 6

5
Front Panel
Rear Panel
1
2
3
4
Front Panel
INPUT
OUTPUT
PE
COMMON NEGATIVE
Rear Panel
CN1
LIN (For Future Use)
Remote Port (Programming Port)
Battery Temperature Sensor
DIP Switches
1
2
3
4
5
3 1 4 2
1 2 3 4 5
