Affinity Instructions for Use - US Page 44
the curve and a frequency and intensity label will be displayed
at the curser’s position, as illustrated below:
Stimulus Selection allows for selecting a test stimulus. The
dropdown is only present for custom made test protocols. The
standards (e.g. ANSI and IEC) have fixed stimuli.
Monitor: If you wish to listen to the amplified stimulus through a
monitor.
1. Connect a monitor speaker the monitor output on the
hardware.
2. Tick the Monitor check box.
3. Use the slider to turn the sound level up and down.
Note that the sound from the monitor may be very soft (compared
to the audiometry monitoring). It is louder for audiometry because
the audiometric equipment is producing the signal that is
monitored. In HIT440 the hearing instrument produces the
monitored signal meaning that it cannot be controlled by the
equipment. However, if you have an active speaker it will be
louder.
External sound: You can present an external sound through for
example a CD player if you have a piece of music/speech you
wish to use. This may have a strong effect for counselling
purposes.
1. Connect the CD player to the CD1 input on the hardware.
2. Press START in the software and then tick the External
sound check box. The external sound will then play
together with the signal.
3. Use the slider to turn the sound level up and down.
Current Protocol is listed in the lower left hand corner.
The
indicates the test is a part of an automatic test flow
(Auto Run). When pressing START all tests with the tick
mark will be performed.
If you wish to perform one test only,
mark it using the mouse by clicking on
it. Then right click at select Run this
test
.
Upon performing a test the system automatically jumps to
the next one in the test flow.
indicates that a curve has
been measured.
Colour indication
shows the colour selected for each curve.
Test protocols can be created
and adjusted in the HIT440
Setup.
