Service Manual

AT235

2.3.2 Rotary dial

For dismantling the rotary dial, remove the cover

by flipping it off.

With a screwdriver,

remove the 3 screws holding the

cover in place.

Now, the 3 black screws holding the dial in place

can also be removed with a screwdriver.

The rotary dial can now be

removed from the top

cabinet.

Fig. 20

Fig. 21

Fig. 22

Fig. 23
