Parts List: 250 lb, 500 lb capacity
Item # QTY Part # Description
1 1 601008 jam nut
2 1 220063 4-pin MTA
3 1 603055 loadcell (250, 500 capacity CS1500)
4 1 601008 jam nut
5 1 500742 scale housing
6 1 601003 8-32 nut
7 2 500708 end plate
8 2 500707 battery tube
9 26 600008 6-32 screw
10 4 330030 battery spring
11 2 500706 battery cap plate
12 2 280074 cap plate back spring
13 2 500705 battery cap
14 2 602422 o-ring
15 2 600014 8-32 screw
17 1 603000 safety latch
18 1 500608 swivel
19 1 601055 .250 clevis pin
20 1 601056 cotter pin
21 1 602009 .25-28 shoulder bolt
22 1 500607 hook
23 1 000094 A/D board
24 18 601207 .031 nylon washer
25 2 500703 board mounting strap
26 4 600012 8-32 screw
27 6 601002 6-32 nut
28 4 601311 8-32 vibration mount
29 4 601315 6-32 standoff
30 2 601301 6-32 f/f standoff
31 2 601208 .062 nylon washer
32 1 000092 LED display board
33 1 500737 display plate
34 1 250001,
250087
keypad assembly
35 1 500730 bezel frame
36 2 600163 6-32 screw
37 2 601314 .25 spacer
38 1 502859 heatsink plate
39 2 601313 .19 spacer
40 1 220063 4-pin MTA
41 1 600020 .25-20 torx screw long
42 1 600020 .25-20 torx screw long
43 1 500709 retaining ring
44 1 500710 retaining ring gasket
45 1 500614 top lifting eye assembly
