CS1500, Users
Rev T, June, 2010
Page 29 of 35
Parts List: 1K lb - 20K lb capacity
Item # QTY Part # Description
1 1 000062
000061
000063
loadcell (1K, 2K capacity CS1500)
loadcell (5K, 10K capacity CS1500)
loadcell (20K capacity CS1500)
2 1 603059 yoke assembly
3 1 601804 cotter pin
4 1 603060 yoke pin
5 1 500742 scale housing
6 1 601003 8-32 nut
7 2 500708 end plate
8 2 500707 battery tube
9 26 600008 6-32 screw
10 4 330030 battery spring
11 2 500706 battery cap plate
12 2 280074 cap plate back spring
13 2 500705 battery cap
14 2 602422 o-ring
15 2 600014 8-32 screw
16 4 600023 .25-20 set screw
17 1 500754 eye nut
18 1 500740 loadcell adapter
19 2 600019 .25-20 torx screw short
20 2 600020 .25-20 torx screw long
21 1 500709 retaining ring
22 1 500710 retaining ring gasket
23 1 000094 A/D board
24 18 601207 .031 nylon washer
25 2 500703 board mounting strap
26 4 600012 8-32 screw
27 6 601002 6-32 nut
28 4 601311 8-32 vibration mount
29 4 601315 6-32 standoff
30 2 601301 6-32 f/f standoff
31 2 601208 .062 nylon washer
32 1 000092 LED display board
33 1 500737 display plate
34 1 250001,
250087
keypad assembly
35 1 500730 bezel frame
36 2 600163 6-32 screw
37 2 601314 .25 spacer
38 1 502859 heatsink plate
39 2 601313 .19 spacer
40 1 220063 4-pin MTA
