Printer Ticket
The printer ticket output is an externally available signal designed to drive a printer or a
computer's RS-232 input.
Transmitted data:
G*xxxxxxx*lb<cr><lf>
N*xxxxxxx*lb<cr><lf>
T*xxxxxxx*lb<cr><lf>
<cr><lf>
TOT**xxxxxxx*lb<cr><lf>
PEAK*xxxxxxx*lb<cr><lf>
<cr><lf>
<cr><lf>
The items have the following meanings:
Item Meaning ASCII Hex ASCII Decimal
G Gross weight 47 71
N Net weight 4E 78
T Tare 54 84
TOT Total accumulated
PEAK Peak weight
lb pounds
kg kilograms
xxxxxxx data
* space 20 32
<cr> carriage return 0D 13
<lf> linefeed 0A 10
NOTE: The “lb” in the printout will be replaced by “kg” if the CS1500 is in kilograms
units.
NOTE: The xxxxxxx field has a fixed length of 7 digits and could contain spaces, a
decimal point, and/or a minus sign.
